Briley barrel bushing

Post by LenV on 6/8/2015, 1:53 pm

Has anyone tried one of these bushings? It looks like a neat way to go for a RO. They come in drop in or gunsmith required. I might have to give one a test drive. Thanks in advance for any input.

Len

http://www.midwayusa.com/product/875045/briley-drop-in-spherical-barrel-bushing-with-581-ring-1911-government-stainless-steel?cm_vc=wishList
avatar
LenV

Posts : 2531
Join date : 2014-01-24
Age : 67
Location : Oregon

Back to top Go down

Re: Briley barrel bushing

Post by Jon Eulette on 6/8/2015, 2:01 pm

I personally don't care for them.  In my experience the slide to bushing fit can be nicely done, but you have play between the bushing and ring an the ring and barrel. So the tolerances grow. Not good for BE.
Jon
avatar
Jon Eulette

Posts : 1694
Join date : 2013-04-15
Location : Southern Kalifornia

Back to top Go down

Re: Briley barrel bushing

Post by james r chapman on 6/8/2015, 2:14 pm

You want it on a straight bbl also. The ring catches on an undercut bbl.
avatar
james r chapman

Posts : 2117
Join date : 2012-01-31
Age : 68
Location : HELL, Michigan

Back to top Go down

Re: Briley barrel bushing

Post by DavidR on 6/8/2015, 3:03 pm

Most good gunsmiths don't thing its good from when I researched it.
avatar
DavidR
Admin

Posts : 2975
Join date : 2011-06-10
Age : 63
Location : NRA:Expert, Georgia

Back to top Go down

Re: Briley barrel bushing

Post by LenV on 6/8/2015, 3:28 pm

I think I have my answer. Gonna take it off my wish list. Thanks all.

Len
avatar
LenV

Posts : 2531
Join date : 2014-01-24
Age : 67
Location : Oregon

Back to top Go down

Re: Briley barrel bushing

Post by Froneck on 6/8/2015, 4:02 pm

I never had one, seem to be good idea but everyone I know that tried them didn't have much good to say about them. Maybe it's in the way they are made! Good idea to remove it from your list.

Froneck

Posts : 844
Join date : 2014-04-05
Age : 70

Back to top Go down

Re: Briley barrel bushing

Post by Jerry Keefer on 6/8/2015, 5:40 pm

OldMaster65 wrote:Has anyone tried one of these bushings? It looks like a neat way to go for a RO. They come in drop in or gunsmith required. I might have to give one a test drive. Thanks in advance for any input.

Len

http://www.midwayusa.com/product/875045/briley-drop-in-spherical-barrel-bushing-with-581-ring-1911-government-stainless-steel?cm_vc=wishList

Len, years ago I used a lot of them.. And had  some record setters..They will shoot.. One major problem, the average shooter will not keep them wet/lubed.. They must stay wet.. I no longer use them in competition guns, BUT, I use them almost every day.. I have a wide assortment of sizes, and use them when fitting barrels. The spring factor is completely eliminated when fitting. Once I have my lugs in the ball park, I remove the Briley, and fit the  bushing..


Last edited by Jerry Keefer on 6/24/2016, 11:43 am; edited 1 time in total
avatar
Jerry Keefer

Posts : 1001
Join date : 2012-01-02
Location : Maidens, VA

Back to top Go down

Re: Briley barrel bushing

Post by 9146gt on 6/8/2015, 8:34 pm

S&W has used them for many years on their Performance Center guns. My 845 shoots the best on the models i have. 845 and 4 versions of the 9mm PPC 9's.

It is my understanding that Briely made all the early barrels for the Performance Center.

Tom

9146gt

Posts : 51
Join date : 2012-03-21
Location : NC

Back to top Go down

Re: Briley barrel bushing

Post by james r chapman on 6/8/2015, 9:42 pm

Hoarder...lol
avatar
james r chapman

Posts : 2117
Join date : 2012-01-31
Age : 68
Location : HELL, Michigan

Back to top Go down

Re: Briley barrel bushing

Post by LenV on 6/8/2015, 10:50 pm

I hate and love the one on my 952. I don't understand why they had to make it out of round. At least they could have put a little mark on it that said "this side up dummy". I keep it well lubed and the 952 shoots great it is just a bear to get back together ( yea, I finally put a little mark on it) That pistol is why I wondered how well these would work for a 1911.

Len
avatar
LenV

Posts : 2531
Join date : 2014-01-24
Age : 67
Location : Oregon

Back to top Go down

Re: Briley barrel bushing

Post by bobthenailer on 6/15/2015, 6:00 am

I have used two of them with excellent results ! i used the oversized outside dia bushing and used there special tool to turn down the outside dia of the bushing for a tight fit to the slide.

bobthenailer

Posts : 24
Join date : 2014-09-05
Location : Southwestern PA

Back to top Go down

Re: Briley barrel bushing

Post by Froneck on 6/15/2015, 6:27 am

Seems with these good reviews it might be a good idea for me to try one.  Out of round Len? How do you find it? Is the barrel hole not concentric with the ball??

Froneck

Posts : 844
Join date : 2014-04-05
Age : 70

Back to top Go down

Re: Briley barrel bushing

Post by LenV on 6/15/2015, 9:04 am

Frank,  They did it on purpose for the 952 series. I guess they didn't want the bushing to float inside the collar. If you read the reviews on the 952s that seems to be the only thing that most owners complain about. Most of the time I don't remove the barrel completely when cleaning. If it was something easy to see that would be different but you have to keep rolling the bushing till it finally lines up. I put the bushing  back on my wish list.

Len


Quote:

"The only negative to the 952 is reassembly after field stripping for cleaning. DM my range partner called me to inform me after getting it field stripped he was having a very hard time with reassembly. I had no ideas at the time but after searching on the internet it seems this is a common issue with the 952. The 952 has a bushing that will rotate freely when removing the barrel. If this bushing is not in perfect alignment with the barrel upon reassembly things will not go back together just right."


Last edited by OldMaster65 on 6/15/2015, 10:48 am; edited 1 time in total (Reason for editing : added quote from a field review)
avatar
LenV

Posts : 2531
Join date : 2014-01-24
Age : 67
Location : Oregon

Back to top Go down

Re: Briley barrel bushing

Post by Ghillieman on 6/15/2015, 9:40 am

The barrel only needs a tight fit when it locks up. A solid bushing with a proper fit will lock up tighter and allow more tolerance when the pistol unlocks and needs it to function. Cheaper and more reliable too.
avatar
Ghillieman

Posts : 366
Join date : 2012-02-14
Location : TEXAS

Back to top Go down

Re: Briley barrel bushing

Post by kwixdraw on 6/16/2015, 11:08 am

Im not going to say they are the answer but I have had good luck with them. I replaced a series 70 collet bushing on my duty gun with one years ago and it has functioned quite reliably for many years. That old Colt still shoots tighter groups than most shooters can. It's a cheap enough way to see if you can get just a little more out of an RO.
avatar
kwixdraw

Posts : 221
Join date : 2014-09-03
Location : Scott County TN

Back to top Go down

Re: Briley barrel bushing

Post by LenV on 6/16/2015, 2:55 pm

I ordered a .582 Briley today. I will post here when I find out if it is improves the group or not. Like kwixdraw said it is a cheap enough way to experiment with.

Len
avatar
LenV

Posts : 2531
Join date : 2014-01-24
Age : 67
Location : Oregon

Back to top Go down

Re: Briley barrel bushing

Post by james r chapman on 6/17/2016, 1:48 pm

OldMaster66 wrote:I ordered a .582 Briley today. I will post here when I find out if it is improves the group or not. Like kwixdraw said it is a cheap enough way to experiment with.

Len

Well???
:-)

avatar
james r chapman

Posts : 2117
Join date : 2012-01-31
Age : 68
Location : HELL, Michigan

Back to top Go down

Re: Briley barrel bushing

Post by LenV on 6/17/2016, 3:31 pm

Well???, The Briley is in my spare parts bin. I measured the barrel a bazillion times and still ordered a bushing that was a little too big. Someday I will have a barrel it fits. I did try it but the group size got larger. Crying or Very sad
avatar
LenV

Posts : 2531
Join date : 2014-01-24
Age : 67
Location : Oregon

Back to top Go down

Re: Briley barrel bushing

Post by james r chapman on 6/17/2016, 3:58 pm

Shucks
avatar
james r chapman

Posts : 2117
Join date : 2012-01-31
Age : 68
Location : HELL, Michigan

Back to top Go down

Re: Briley barrel bushing

Post by Jerry Keefer on 6/17/2016, 5:32 pm

james r chapman wrote:Shucks
James
You can look this up.. 2001 Jackson, Miss.  Nationals
Two Man Team winners/ record set by Richmond PD Mike Talbert and Jason Yurema
The record stood for nearly ten years.
Both guns were equipped with Brileys.
Both guns are still running with the same Brileys.. and still winning matches.. Yurema no longer shoots, but Talbert still wins his share.
The Briley requires the same effort to install at minimum tolerances and clearances as any other part.  The ring is not eccentric. The eccentric is machine inside the bushing to enable removing, and installing new or different sized rings. It is tricky to remove and install them, as the clearance is metal to metal. But, there seldom a reason to remove the ring  on the 1911 set up.. I am not familiar with the S&W series..
Run them wet....
avatar
Jerry Keefer

Posts : 1001
Join date : 2012-01-02
Location : Maidens, VA

Back to top Go down

Re: Briley barrel bushing

Post by LenV on 6/18/2016, 6:06 pm

I guess I will give it another try. I just realized that I had purchased several new barrels since I put the Briley into the parts bin. I have a 38 super barrel in my RO that it fits perfectly. After spending several hours finding my recoil spring plug* and 2 minutes actually swapping it out it is ready to take to the field. Once again I hope to be able to give a report sometime.

* The "Real Avid" 1911 smart wrench works great for taking a 1911 apart. They suck for getting them back together.

Len
avatar
LenV

Posts : 2531
Join date : 2014-01-24
Age : 67
Location : Oregon

Back to top Go down

Re: Briley barrel bushing

Post by james r chapman on 6/18/2016, 6:13 pm

Well???


(Lol)
avatar
james r chapman

Posts : 2117
Join date : 2012-01-31
Age : 68
Location : HELL, Michigan

Back to top Go down

Re: Briley barrel bushing

Post by Wes Lorenz on 6/24/2016, 10:54 am

While waiting for an angle bored bushing from EGW, I used a .583" dia Briley bushing (use it for fitting barrels) in two 2700's with only one ammo related refire. Barrel is a Kart .5805" greased with molylube from Larrys Guns.

Wes Lorenz

Posts : 122
Join date : 2011-06-27
Location : Washington

Back to top Go down

Re: Briley barrel bushing

Post by Froneck on 6/24/2016, 11:07 am

I will soon find how good they are. Ordered 2 from Brownells, one for a 1911 I'm building for myself and another for a Gold Cup I'm doing for a friend. I do have Jig Borers and intend to make a double bored bushing that will be bored while the bushing is in the slide and matching the barrel location in both open and closed positions.

Froneck

Posts : 844
Join date : 2014-04-05
Age : 70

Back to top Go down

Re: Briley barrel bushing

Post by Jerry Keefer on 6/24/2016, 11:39 am

Wes Lorenz wrote:While waiting for an angle bored bushing from EGW, I used a .583" dia Briley bushing (use it for fitting barrels) in two 2700's with only one ammo related refire. Barrel is a Kart .5805" greased with molylube from Larrys Guns.
Hello Wes..
How did shoot for you..??
Some where, I have an angle bore from EGW..Can't find it.. I love George's parts and innovation, he's always ahead of the curve,  but I didn't care for the double angle bore for bullseye. I think it takes away to much bearing surface.  But that's just me.. It might work great for you.. When I angle bored bushings, I fit the barrel with a tight Briley.. Then I locked the barrel to the slide, mounted it on a sine plate, and measured the angle of lock up.. Then I used that to bore the angle.. The 52' minute thing is arbitrary..  But now... I am all cone..Smile
avatar
Jerry Keefer

Posts : 1001
Join date : 2012-01-02
Location : Maidens, VA

Back to top Go down
