Post by Jerry Keefer on 1/24/2015, 12:14 am

First topic message reminder :

Some where, Jon and I were talking about the two.. I can't find it now.. But here's a pic of a freshly machined cone, ready to install..
Cones vs Bushings - Page 2 IMG_1667_zpsiuqapsbv
Cones vs Bushings - Page 2 IMG_1689_zpslqtplctcCones vs Bushings - Page 2 IMG_1669_zpsposuiiah


Last edited by Jerry Keefer on 1/26/2015, 3:27 pm; edited 1 time in total
Jerry Keefer
Jerry Keefer

Posts : 1001
Join date : 2012-01-02
Location : Maidens, VA

Back to top Go down


Cones vs Bushings - Page 2 Empty Re: Cones vs Bushings

Post by dstates on 1/28/2015, 12:26 pm

I'm new to 1911's... does anyone have a cutaway of a cone setup so I can understand the setup better?

Doug

dstates

Posts : 198
Join date : 2013-03-05
Location : Near Moline, IL

Back to top Go down

Cones vs Bushings - Page 2 Empty Re: Cones vs Bushings

Post by Jerry Keefer on 1/28/2015, 1:14 pm

38Super!! wrote:
Re your earlier post above on the subject, was there a noticeable reduction in recoil for your lady shooter for which you or she can attribute in aiding her shooting ability by using a coned barrel after her injury?

Given her noteworthy rapid rise to Master, one has to wonder if the coned barrel played a a role?

Hard work on her part and superb support on yours in more than just gunsmithing surely were the critical factors.

Finally, her exemplary performance at Perry last year as well as that at Cavalier in the recent past and subsequent rise to Master has given us who languish in the Expert class new hope to fare better in the standings at Cavalier.

Cheers
Smile Smile
I did a comparison of weights..
The cone adds  approx. one ounce to the barrel. The over all outcome in  her case was the sum of many other modifications which are more race gun than traditional bullseye gun. Again I thank Chuck Warner for his advice as a race gun builder.. The slide has been lightened considerably, and cycles very quickly. It matters somewhat where that weight is removed.. Taking the optics off the slide helped a lot!! Lead only projectiles at bullseye velocities, and springs that assist in recoil recovery during sustained fire.
In this pic you can see the slide  has cycled completely, the casing can be seen still in the air close to her thumb, there is some cant, but her arm is very close to its original attitude.. I have lost count of the RFs she has cleaned..
 Cones vs Bushings - Page 2 50f5cfffe5aea.image_zpswh8oyqah
Jerry Keefer
Jerry Keefer

Posts : 1001
Join date : 2012-01-02
Location : Maidens, VA

Back to top Go down

Cones vs Bushings - Page 2 Empty Re: Cones vs Bushings

Post by Steve B on 1/28/2015, 5:09 pm

DavidR wrote:What is the cost to have you switch a bushing gun to a cone on say a range officer?

Unfortunately, there's only a few guys I'd trust to do one.  Joe Chambers, Bob Marvel, Jerry Keefer are the only ones who come to mind.  The last 2, even more unfortunately, are no longer taking on customers.  You would want to do a full accuracy refit so I'm sure you'd be looking at 2.5-3k.  When Joe finishes my wad gun I'll post pictures...

Jerry, is there anyone else you recommend for this type of barrel work?

Steve B

Posts : 435
Join date : 2011-06-16
Location : Elkhart, IN

Back to top Go down

Cones vs Bushings - Page 2 Empty Re: Cones vs Bushings

Post by Jerry Keefer on 1/28/2015, 7:28 pm

Sorry Steve,
I can't think of anyone else who is using the cone..
Jerry Keefer
Jerry Keefer

Posts : 1001
Join date : 2012-01-02
Location : Maidens, VA

Back to top Go down

Cones vs Bushings - Page 2 Empty Re: Cones vs Bushings

Post by Jerry Keefer on 1/28/2015, 7:33 pm

dstates wrote:I'm new to 1911's... does anyone have a cutaway of a cone setup so I can understand the setup better?

Doug
Doug
I'll make a pic of the barrel and cone assembly tomorrow...

Cones vs Bushings - Page 2 IMG_1701_zpspmrajvpk


Last edited by Jerry Keefer on 1/29/2015, 11:36 am; edited 1 time in total
Jerry Keefer
Jerry Keefer

Posts : 1001
Join date : 2012-01-02
Location : Maidens, VA

Back to top Go down

Cones vs Bushings - Page 2 Empty Re: Cones vs Bushings

Post by dstates on 1/28/2015, 7:59 pm

Thanks, Jerry

dstates

Posts : 198
Join date : 2013-03-05
Location : Near Moline, IL

Back to top Go down

Cones vs Bushings - Page 2 Empty Re: Cones vs Bushings

Post by Jerry Keefer on 1/29/2015, 11:39 am

tt
Jerry Keefer
Jerry Keefer

Posts : 1001
Join date : 2012-01-02
Location : Maidens, VA

Back to top Go down

Cones vs Bushings - Page 2 Empty Re: Cones vs Bushings

Post by marlin1881 on 1/29/2015, 4:27 pm

Jerry,  What keeps the cone in the slide?  I'm missing that part of the puzzle.

marlin1881

Posts : 44
Join date : 2011-06-11
Location : Northern Colorado

Back to top Go down

Cones vs Bushings - Page 2 Empty Re: Cones vs Bushings

Post by Jerry Keefer on 1/29/2015, 4:54 pm

It's locked onto the barrel..so the slide ID is the bushing..
Jerry Keefer
Jerry Keefer

Posts : 1001
Join date : 2012-01-02
Location : Maidens, VA

Back to top Go down

Cones vs Bushings - Page 2 Empty Re: Cones vs Bushings

Post by knightimac on 1/30/2015, 1:02 pm

OH Crap.

Sounds like cones are great.  But I'll likely never see one!

Sad
knightimac
knightimac

Posts : 195
Join date : 2014-03-16
Location : Auburn, Pa

Back to top Go down

Cones vs Bushings - Page 2 Empty Self qurrantine

Post by 8eightring on 3/25/2020, 8:42 pm

Being stuck in the house during this convid 19 thing is tuff. I decided to make my own cone for a 1911 9MM barrel that didn't quite fit up the way i wanted it to. This is for a pistiol that I shoot steel with so it is not exactly a Bullseye topic.
Attachments
Cones vs Bushings - Page 2 Attachment
20200325_162047.jpg Rough machined and ready for the LoctiteYou don't have permission to download attachments.(179 Kb) Downloaded 7 times
Cones vs Bushings - Page 2 Attachment
20200325_161902.jpg You don't have permission to download attachments.(139 Kb) Downloaded 3 times
Cones vs Bushings - Page 2 Attachment
20200325_165438.jpg Loctite togetherYou don't have permission to download attachments.(106 Kb) Downloaded 3 times
Cones vs Bushings - Page 2 Attachment
20200325_212224.jpg Finish machined, fit to slide and polishedYou don't have permission to download attachments.(209 Kb) Downloaded 3 times

8eightring

Posts : 19
Join date : 2011-06-16
Location : Ohio

Back to top Go down

Cones vs Bushings - Page 2 Empty Re: Cones vs Bushings

Post by jglenn21 on 3/25/2020, 8:47 pm

Good choice on the locktite 680..
jglenn21
jglenn21

Posts : 1969
Join date : 2015-04-07
Age : 71
Location : monroe , ga

Back to top Go down

Cones vs Bushings - Page 2 Empty Re: Cones vs Bushings

Post by REConley on 3/25/2020, 10:19 pm

Jerry Keefer wrote:Yes, cones have been around a long time... Someone researched it on another forum, and was able to closely determine the origin. I have only been doing them for about 5 years now.. Bob Marvel used them, Joe Chambers, and Chuck Warner a noted race gun builder, influenced me to give them a try in an effort to reduce recoil for my lady shooter after her injury.. I really like them..
Jim Stroh made many barrels similar to the coned compensated Clark pictured above.. I have many of his prints, and they are dated
late 80s early 90s


This is the first 38 Super Comp pistol built by Jim. I believe it was 1985 when it was completed.
Cones vs Bushings - Page 2 38_sup10
REConley
REConley

Posts : 49
Join date : 2019-12-06
Location : Georgia

Back to top Go down

Cones vs Bushings - Page 2 Empty Re: Cones vs Bushings

Post by 1joel1 on 3/26/2020, 10:41 am

8eightring wrote:Being stuck in the house during this convid 19 thing is tuff.

I'm curious, is "convid 19" a typo or are you trying to imply something?

1joel1

Posts : 336
Join date : 2012-11-09
Location : San Diego, CA

Back to top Go down

Cones vs Bushings - Page 2 Empty Re: Cones vs Bushings

Post by 8eightring on 3/26/2020, 10:48 am

typo

8eightring

Posts : 19
Join date : 2011-06-16
Location : Ohio

Back to top Go down

Cones vs Bushings - Page 2 Empty Re: Cones vs Bushings

Post by 10sandxs on 3/26/2020, 12:46 pm

This is timely... my current project... the barrel is 6+ inches and the brass is only a muzzle weight... going to make an aluminium one as well to try different weights.

Cones vs Bushings - Page 2 20200310Cones vs Bushings - Page 2 20200310

10sandxs

Posts : 321
Join date : 2016-01-29

Back to top Go down

Cones vs Bushings - Page 2 Empty Re: Cones vs Bushings

Post by troystaten on 3/26/2020, 3:12 pm

Interesting stuff, nice to see people experimenting with various ideas.
