1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 Empty 1911/45 wadcutter 1 X14 twist Douglas being born..

Post by Jerry Keefer Sat Feb 20, 2016 9:08 pm

First topic message reminder :

1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 IMG_0226_zpsofk9vika
1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 IMG_0227_zpstxgvsp961911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 IMG_2704_zpsulah5kyj
1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 IMG_2710_zps1kyqn2dm
Jerry Keefer
Jerry Keefer

Posts : 1001
Join date : 2012-01-02
Location : Maidens, VA

Back to top Go down


1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 Empty Re: 1911/45 wadcutter 1 X14 twist Douglas being born..

Post by Jerry Keefer Sun Feb 28, 2016 2:37 pm

Working on the hood
Cutting a chamfer on the hood edges, prevents them from bottoming out in the slide and creating a false reading, which often results in a short hood..
1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 IMG_2758_zpsxrmpjg581911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 IMG_2759_zpsvilcfbuw
Jerry Keefer
Jerry Keefer

Posts : 1001
Join date : 2012-01-02
Location : Maidens, VA

Back to top Go down

1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 Empty Re: 1911/45 wadcutter 1 X14 twist Douglas being born..

Post by kc.crawford.7 Mon Feb 29, 2016 6:41 am

Well Jerry it is a seamless fit.  There is no seam.................... lol! Laughing
kc.crawford.7
kc.crawford.7

Posts : 718
Join date : 2012-12-09
Location : Maysville, NC

http://www.kcskustomcreations.com

Back to top Go down

1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 Empty Re: 1911/45 wadcutter 1 X14 twist Douglas being born..

Post by james r chapman Mon Feb 29, 2016 9:17 am

kc.crawford.7 wrote:Well Jerry it is a seamless fit.  There is no seam.................... lol! Laughing

So it seems!
james r chapman
james r chapman
Admin

Posts : 6220
Join date : 2012-01-31
Age : 75
Location : HELL, Michigan

Back to top Go down

1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 Empty Re: 1911/45 wadcutter 1 X14 twist Douglas being born..

Post by Wobbley Mon Feb 29, 2016 11:31 am

G R O A N!
Wobbley
Wobbley
Admin

Posts : 4650
Join date : 2015-02-13

Back to top Go down

1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 Empty Re: 1911/45 wadcutter 1 X14 twist Douglas being born..

Post by Jerry Keefer Tue Mar 08, 2016 9:00 pm

Took some time off from the barrels to get the IRS and SS regulations out of the way..still a few loose ends to finalize.. I dread it..
Profiling the front angle enough to get the lug cutter in.. Final cuts will be after the lower lug is fit.., and putting a clearance cut at 12 o clock in the upper  lug to prevent high centering..
1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 IMG_2773_zpsjvmq88ax
1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 IMG_2777_zpsgtb591kp1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 IMG_2769_zpssyvc6mw2
Jerry Keefer
Jerry Keefer

Posts : 1001
Join date : 2012-01-02
Location : Maidens, VA

Back to top Go down

1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 Empty Re: 1911/45 wadcutter 1 X14 twist Douglas being born..

Post by rich.tullo Wed Mar 09, 2016 11:21 am

I'll buy one if available in with a  bushing one for a EIC Service Pistol I want to build.
rich.tullo
rich.tullo

Posts : 1944
Join date : 2015-03-27

Back to top Go down

1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 Empty Re: 1911/45 wadcutter 1 X14 twist Douglas being born..

Post by Chris Miceli Thu Mar 31, 2016 11:37 am

I haven't had my 1:14 twist porn fix for a while  Sad Sad Sad

Chris Miceli

Posts : 2715
Join date : 2015-10-27
Location : Northern Virginia

Back to top Go down

1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 Empty Re: 1911/45 wadcutter 1 X14 twist Douglas being born..

Post by Jerry Keefer Thu Mar 31, 2016 4:51 pm

Sorry...burning both ends of the candle  lately, plus,  thought it might becoming a bore.. {groan} Shocked    First 2700 is Saturday the  2nd.   It is shooting very well.. Over 1000 rounds thru it to date. Best 50 yd line is 98 so  far..The shooter is elated with the feel. Says it is on par with her 52 shortline recoil.. She is smoking the short line..
 I got excited and started on a 12 twist.. Smile
Jerry Keefer
Jerry Keefer

Posts : 1001
Join date : 2012-01-02
Location : Maidens, VA

Back to top Go down

1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 Empty Re: 1911/45 wadcutter 1 X14 twist Douglas being born..

Post by jmdavis Thu Mar 31, 2016 10:27 pm

Is that the one she has been practicing with? If so, it looked very smooth in slow fire. I didn't watch any sustained that day.
jmdavis
jmdavis

Posts : 1409
Join date : 2012-03-24
Location : Virginia

Back to top Go down

1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 Empty Re: 1911/45 wadcutter 1 X14 twist Douglas being born..

Post by Jerry Keefer Fri Apr 01, 2016 6:12 am

jmdavis wrote:Is that the one she has been practicing with? If so, it looked very smooth in slow fire. I didn't watch any sustained that day.
Yes...I have been too busy to accompany her. Her targets are much improved.
Jerry Keefer
Jerry Keefer

Posts : 1001
Join date : 2012-01-02
Location : Maidens, VA

Back to top Go down

1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 Empty Re: 1911/45 wadcutter 1 X14 twist Douglas being born..

Post by Jerry Keefer Sat May 14, 2016 9:56 pm

A  little equipment up grade with a new taper attachment to facilitate  those tapered cones...SmileSmile
1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 IMG_3053_zpsmoyaujc8
Here I am working on a prototype 1911 gunsmith tool.. truing two blocks of 4140 pre hardened before layout.. Jo Block quality.. another seamless job..Smile
1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 IMG_3052_zpsxhhihuq1
Jerry Keefer
Jerry Keefer

Posts : 1001
Join date : 2012-01-02
Location : Maidens, VA

Back to top Go down

1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 Empty Re: 1911/45 wadcutter 1 X14 twist Douglas being born..

Post by Jerry Keefer Mon May 23, 2016 10:33 pm

Perry is fast approaching.. The 14 twist, one  lug barrel barrel in the above thread, has many thousand thru it and is doing so well that I am anxiously working on this 12 twist.. Closing in on finish.. Here I centered the lower lug with the bore line and roughed out the link slot..
1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 IMG_3069_zpstky5l8dl
1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 IMG_3070_zpser3z1jwq
Jerry Keefer
Jerry Keefer

Posts : 1001
Join date : 2012-01-02
Location : Maidens, VA

Back to top Go down

1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 Empty Re: 1911/45 wadcutter 1 X14 twist Douglas being born..

Post by Chris Miceli Mon May 23, 2016 11:59 pm

I feel like a cnc would save you lots of time Smile

Chris Miceli

Posts : 2715
Join date : 2015-10-27
Location : Northern Virginia

Back to top Go down

1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 Empty Re: 1911/45 wadcutter 1 X14 twist Douglas being born..

Post by DavidR Tue May 24, 2016 10:49 am

I bet he has one he has everything else,
DavidR
DavidR
Admin

Posts : 3032
Join date : 2011-06-10
Age : 70
Location : NRA:Expert, Georgia

Back to top Go down

1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 Empty Re: 1911/45 wadcutter 1 X14 twist Douglas being born..

Post by SNaymola Tue May 24, 2016 3:24 pm

Jerry Keefer wrote:Perry is fast approaching.. The 14 twist, one  lug barrel barrel in the above thread, has many thousand thru it and is doing so well that I am anxiously working on this 12 twist.. Closing in on finish.. Here I centered the lower lug with the bore line and roughed out the link slot..

Jerry, does the sharp step on the barrel lug where the slide stop pin rides over and rests, get cut out later, or is it part of the final design?
Stan

SNaymola

Posts : 39
Join date : 2013-11-25

Back to top Go down

1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 Empty Re: 1911/45 wadcutter 1 X14 twist Douglas being born..

Post by Jerry Keefer Tue May 24, 2016 4:40 pm

Yes, it is not any where near final fit.. I rough it out so I can get enough clearance to cut the link slot to depth.. Even then, that slot is tricky to get right..I ground a special cutter to get the depth,, and width.  The slot is .135
 I am roughing the slot with an endmill to take the load off the woodruff cutter and create chip clearance.
Jerry Keefer
Jerry Keefer

Posts : 1001
Join date : 2012-01-02
Location : Maidens, VA

Back to top Go down

1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 Empty Re: 1911/45 wadcutter 1 X14 twist Douglas being born..

Post by Jerry Keefer Mon Jun 13, 2016 4:59 pm

Decided to make a fixture to enhance finishing the barrels..[since I am no  longer buying barrels..Smile]  This is ground square and true in relation to the lower lugs.
I can now install the barrel. Layout the roughing cuts and move to the mill without losing a zero.. It will also aid greatly in chambering / crowning to align X-Z axis
This is a 12 twist I hope to finish for Perry..
1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 IMG_3147_zpszrshfqpj
1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 IMG_3153_zpsnaojxkne
1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 IMG_3154_zpswuffpizb
1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 IMG_3155_zpsoio7ol3h
1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 IMG_3160_zpsuezngsfo1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 IMG_3161_zpssr6iahv6
Jerry Keefer
Jerry Keefer

Posts : 1001
Join date : 2012-01-02
Location : Maidens, VA

Back to top Go down

1911/45  wadcutter 1 X14 twist Douglas being born.. - Page 2 Empty Re: 1911/45 wadcutter 1 X14 twist Douglas being born..

Post by Chris Miceli Mon Jun 13, 2016 5:16 pm

That is some neat stuff Jerry!

Chris Miceli

Posts : 2715
Join date : 2015-10-27
Location : Northern Virginia

Back to top Go down
